Role of Emergency Vents in Tank Safety
Emergency vents protect an internal fuel tank from being over-pressurised. It allows the tank to release the pressure and ensure safety in the event of a fire. In other words, emergency vents are pressure releasing devices preventing the tank from being ruptured due to over pressurising.
If a fire takes place near a flammable liquid storage tank, the heat passed on by the tank wall to its contents will cause vaporisation of the liquid inside. If the tank holds petroleum-based products, the expected vaporisation is about 30 or more cubic feet for every gallon of solvent. This act is bound to create a relatively high pressure within the tank, and if there’s no emergency vent available, the tank may rupture, leading to a disaster.
Such explosions can be avoided by having an emergency relief vent to allow the vapours to escape from the tank. Most emergency vents feature pallet assemblies that stay close under normal pressure and open when a predetermined pressure is reached. This relieves the abnormal volume of vapour created in case of fire conditions.
Emergency vents are essential to be installed in tanks storing flammable substances. At Ekotech, we stock and supply a range of emergency vents to meet the varying needs of fire-rated tanks.
Choose The Ideal Product For Your Storage Tank
We have stocked various emergency vents in our collection to meet the needs of all types of tanks. Therefore, buying a vent from us will guarantee your products that are:
- Light in weight – Most of the emergency vents we stock are light weight, so you can easily handle them and install them on aboveground tanks.
- Sturdy – All the products are made using sturdy and durable materials, so once you buy an emergency vent from us, you will not have to replace it for years.
- Easy to Mount – The design of our vents is such that most of them can be mounted horizontally or vertically, depending on the space available.
- Easy to set up – Most of our emergency vents require no additional parts, so setting them to put them in use is easy.
- Factory tested – Many of the products in our stock are factory tested and certified for leakages and appropriate settings.
We have a wide choice of Emergency Vents for providing additional pressure relief to accommodate extraordinary conditions such as fire exposure to a tank or full-open failure of a blanketing valve. We can supply you with a range of Emergency Vents suitable for most industrial applications.
Speak To Us To Find Out More Details About Our Products
If you are looking to purchase the right emergency vent for your liquid storage tank, you must go through our collection of high-quality vents. All the specifications of each product are mentioned on our website for your reference. If you still have queries about the features or functioning of our emergency vents, you can call us on (03) 9457 3700 or drop us an email at [email protected]. We also have an enquiry form on the contact us page for you to fill in. You can put your concerns in the form, and we will get back to you at the earliest.
Ekotech sells other industrial products like liquid level gauges, bursting discs and panels, sight flow indicators, and pressure vacuum vents.
SERIES 7800
SERIES 51700
SERIES 52600
SERIES 53300
SERIES 54000
Pressure Vacuum Vents
SERIES 830
Series 6240
Series 7800
SERIES 8540
SERIES 8740
SERIES 16240
SERIES 17800
SERIES 18540
FRP VENTS
SPRING LOADED
Tank Blanketing Valves
Tank Blanketing Valves provide an effective means of preventing and controlling fires in flammable liquid storage tanks. Vapours cannot be ignited in the absence of an adequate supply of oxygen. In most instances, this oxygen is provided by air drawn into the tank from the atmosphere during tank emptying operations.
Tank Blanketing Valves are installed with their inlet connected to a supply of pressurized inert gas (usually Nitrogen), and their outlet piped into the tank's vapour space. When the tank pressure drops below a predetermined level, the blanketing valve opens and allows a flow of inert gas into the vapour space. The blanketing valve reseals when pressure in the tank has returned to an acceptable level. The blanketing gas contains no air. No supply of air (Oxygen) is allowed to enter the tank. The vapours, therefore, never form a flammable mixture.
Tank Blanketing Valves help maintain the vapour space in a non-flammable condition, and also provide make-up gas to insure that the tank's vapour space is not subjected to a vacuum.
Tank Blanketing Valves can also be utilised to protect products such as purified water or cooking oils from contaminants by maintaining a positive pressure in the vapour space of the storage tank.
Series 10
Series 20
Series 30
Gauge Hatches & Specialty Tank Fittings
Ekotech supplies specialty tank fittings including Overflow Valves, Storage Tank Air Dryers (Silica Gel Desiccant Dryers), Floating Suctions and an extensive range of Gauge Hatches (Dip Hatches).
Overflow Valves
Storage Tank Air Dryers
Gauge Hatches
Weatherhood Free Vent
Download PDF (Pressure Vacuum Vents)
- Series 830 End-of-Line Conservation Vent & Flame Arrester
- Series 830E-D End-of-Line Conservation Vent & Flame Arrester
- Series 6240 End-of-Line Vacuum Relief Vent
- Series 7800 End-of-Line Emergency Pressure Vent
- Series 8540 End-of-Line Conservation Pressure / Vacuum Breather Vent
- Series 8740 In-Line Conservation Breather Vent
- Series 16240 Side-Mount Vacuum Relief Vent
- Series 17800 Pipe-Away Conservation Pressure Breather Vent
- Series 18540 Pipe-Away Conservation Pressure / Vacuum Breather Vent
- FRP Vents
- Spring Loaded Vents
